BLOCK RELATED PRODUCTS COMPATIBILITY LIST
| ENGINE | CATEGORY | SPEC [OEM] | PART NO. | |
| NISSAN | ||||
| VR38DETT | STROKER KIT | 4.1L | TOMEI BORE: 95.50mm [+-0.00] | TA201A-NS01A |
| PISTON | for 4.1L | TOMEI BORE: 95.50mm [+-0.00] CH 31.20mm [-3.10] | TA202A-NS01A | |
| CON-ROD | for 4.1L | 165.10mm [+-0.00] | TA203A-NS01A | |
| CRANKSHAFT | for 4.1L | 94.40mm [+6.00] | TA204D-NS01A | |
| VQ35HR | CON-ROD | for 3.5L(STD) | 151.80mm [+-0.00] | TA203A-NS03A |
| VQ35DE | CON-ROD | for 3.5L(STD) | 144.20mm [+-0.00] | TA203A-NS04A |
| RB26DETT | STROKER KIT | 2.8L 8-C.W. | TOMEI BORE: 87.00mm [+1.00] | TA201A-NS05A |
| CP BORE 87.00mm [+1.00] | TA201A-NS05AP | |||
| TOMEI BORE: 86.50mm [+0.50] | TA201A-NS05D | |||
| 2.8L Full-C.W. | TOMEI BORE: 87.00mm [+1.00] | TA201A-NS05B | ||
| CP BORE 87.00mm [+1.00] | TA201A-NS05BP | |||
| TOMEI BORE: 86.50mm [+0.50] | TA201A-NS05E | |||
| 2.6L(STD) Full-C.W. | TOMEI BORE: 87.00mm [+1.00] | TA201A-NS05C | ||
| CP BORE 87.00mm [+1.00] | TA201A-NS05CP | |||
| TOMEI BORE: 86.50mm [+0.50] | TA201A-NS05F | |||
| PISTON | for 2.6L(STD)/2.8L | CH 30.00mm [+-0.00] | TA202A-NS05A | |
CH 30.00mm [+-0.00] | TA202A-NS05AP | |||
CH 30.00mm [+-0.00] | TA202A-NS05B | |||
| CON-ROD | for 2.6L(STD) | 121.50mm [+-0.00] | TA203A-NS05A | |
| for 2.8L | 119.50mm [-2.00] | TA203A-NS05B | ||
| CRANKSHAFT | for 2.6L(STD) | Full-C.W. 73.70mm [+-0.00] | TA204B-NS05A | |
| for 2.8L | Full-C.W. 77.70mm [+4.00] | TA204B-NS05B | ||
| 8-C.W. 77.70mm [+4.00] | TA204C-NS05A | |||
| RB25DET | STROKER KIT | 2.8L 8-C.W. | TOMEI BORE: 87.00mm [+1.00] | TA201A-NS05A |
| CP BORE 87.00mm [+1.00] | TA201A-NS05AP | |||
| TOMEI BORE: 86.50mm [+0.50] | TA201A-NS05D | |||
| 2.8L Full-C.W. | TOMEI BORE: 87.00mm [+1.00] | TA201A-NS05B | ||
| CP BORE 87.00mm [+1.00] | TA201A-NS05BP | |||
| TOMEI BORE: 86.50mm [+0.50] | TA201A-NS05E | |||
| 2.6L(STD) Full-C.W. | TOMEI BORE: 87.00mm [+1.00] | TA201A-NS05C | ||
| CP BORE 87.00mm [+1.00] | TA201A-NS05CP | |||
| TOMEI BORE: 86.50mm [+0.50] | TA201A-NS05F | |||
| PISTON | for 2.6L(STD)/2.8L | CH 30.00mm [+-0.00] | TA202A-NS05A | |
CH 30.00mm [+-0.00] | TA202A-NS05AP | |||
CH 30.00mm [+-0.00] | TA202A-NS05B | |||
| CON-ROD | for 2.5L(STD)/2.6L | 121.50mm [+-0.00] | TA203A-NS05A | |
| for 2.8L | 119.50mm [-2.00] | TA203A-NS05B | ||
| CRANKSHAFT | for 2.6L | Full-C.W. 73.70mm [+-0.00] | TA204B-NS05A | |
| for 2.8L | Full-C.W. 77.70mm [+4.00] | TA204B-NS05B | ||
| 8-C.W. 77.70mm [+4.00] | TA204C-NS05A | |||
| RB25DE(T) NEO6 | CON-ROD | for 2.5L(STD) | 121.50mm [+-0.00] | TA203A-NS05A |
| RB25DE | CON-ROD | for 2.5L(STD) | 121.50mm [+-0.00] | TA203A-NS05A |
| SR20DET | STROKER KIT | 2.2L | TOMEI BORE: 87.00mm [+1.00] | TA201A-NS08A |
| TOMEI BORE: 86.50mm [+0.50] | TA201A-NS08B | |||
| PISTON | for 2.2L | CH 29.50mm [-2.50] | TA202A-NS08A | |
CH 29.50mm [-2.50] | TA202A-NS08C | |||
| for 2.0L(STD) | CH 32.00mm [+-0.00] | TA202A-NS08B | ||
CH 32.00mm [+-0.00] | TA202A-NS08D | |||
| CON-ROD | for 2.0L(STD)/2.2L | 136.30mm [+-0.00] | TA203A-NS08A | |
| CRANKSHAFT | for 2.2L | Full-C.W. 91.00mm [+5.00] | TA204B-NS08A | |
| SR20DE SR18DE | CON-ROD | for 2.0L(STD)/1.8L(STD) | 136.30mm [+-0.00] | TA203A-NS08A |
| KA24DE | CON-ROD | for 2.4L(STD) | 165.00mm [+-0.00] | TA203A-NS16A |
| TOYOTA | ||||
| 4A-G 16VALVE | STROKER KIT | 1.8L | CP BORE: 82.00mm [+1.00] | TA201A-TY01AP |
| PISTON | for 1.8L | CH 27.70mm [-3.00] | TA202A-TY01AP | |
| 4A-G(Z) 16VALVE | CON-ROD | for 1.6L(STD)/1.8L | 122.00mm [+-0.00] | TA203A-TY01A |
| CRANKSHAFT | for 1.8L | Full-C.W. 83.00mm [+6.00] | TA204B-TY01A | |
| 4A-G 20VALVE | STROKER KIT | 1.8L | BORE: 82.00mm [+1.00] | TA201A-TY02AP |
| PISTON | for 1.8L | CH 27.70mm [-3.00] | TA202A-TY02AP | |
| CON-ROD | for 1.6L(STD)/1.8L | 122.00mm [+-0.00] | TA203A-TY01A | |
| CRANKSHAFT | for 1.8L | Full-C.W. 83.00mm [+6.00] | TA204B-TY01A | |
| 2JZ-GTE | STROKER KIT | 3.4L | TOMEI BORE: 87.00mm [+1.00] | TA201A-TY03A |
| CP BORE: 87.00mm [+1.00] | TA201A-TY03AP | |||
| TOMEI BORE: 86.50mm [+0.50] | TA201A-TY03C | |||
| 3.6L | TOMEI BORE: 87.00mm [+1.00] | TA201A-TY03B | ||
| CP BORE: 87.00mm [+1.00] | TA201A-TY03BP | |||
| TOMEI BORE: 86.50mm [+0.50] | TA201A-TY03D | |||
| PISTON | for 3.4L | CH 30.00mm [-4.00] | TA202A-TY03A | |
CH 30.00mm [-4.00] | TA202A-TY03AP | |||
CH 30.00mm [-4.00] | TA202A-TY03D | |||
| for 3.6L | CH 29.50mm [-4.50] | TA202A-TY03B | ||
CH 29.50mm [-4.50] | TA202A-TY03BP | |||
CH 29.50 mm[-4.50] | TA202A-TY03E | |||
| for 3.0L(STD) | CH 34.00mm [+-0.00] | TA202A-TY03C | ||
CH 34.00mm [+-0.00] | TA202A-TY03F | |||
| CON-ROD | for 3.0L(STD)/3.4L | 142.00mm [+-0.00] | TA203A-TY03A | |
| for 3.6L | 139.00mm [-3.00] | TA203A-TY03B | ||
| CRANKSHAFT | for 3.4L | Full-C.W. 94.00mm [+8.00] | TA204B-TY03A | |
| CRANKSHAFT | for 3.6L | Full-C.W. 100.0mm [+14.00] | TA204B-TY03B | |
| 1JZ-GTE | CON-ROD | for 2.5L(STD) | 125.25mm [+-0.00] | TA203A-TY04A |
| SUBARU | ||||
| EJ25 | STROKER KIT | 2.6L | TOMEI BORE: 99.75mm [+0.25] | TA201A-SB02A |
| CP BORE: 99.75mm [+0.25] | TA201A-SB02AP | |||
| PISTON | for 2.5L(STD)/2.6L | CH30.70mm [+-0.00] | TA202A-SB02A | |
CH30.70mm [+-0.00] | TA202A-SB02AP | |||
| CON-ROD | for 2.6L | 127.80mm [-2.70] | TA203A-SB02A | |
| for 2.5L(STD) | 130.50mm [+-0.00] | TA203A-SB01A | ||
| CRANKSHAFT | for 2.6L | Full-C.W. 83.00mm [+4.00] | TA204B-SB02A | |
| EJ20 | CON-ROD | for 2.0L(STD) | 130.50mm [+-0.00] | TA203A-SB01A |
| MITSUBISHI | ||||
| 4G63 | STROKER KIT | 2.2L | TOMEI BORE:86.00mm [+1.00] | TA201A-MT01A |
| CP BORE:86.00mm [+1.00] | TA201A-MT01AP | |||
| TOMEI BORE:85.50mm [+0.50] | TA201A-MT01C | |||
| 2.3L | TOMEI BORE:86.00mm [+1.00] | TA201A-MT01B | ||
| CP BORE:86.00mm [+1.00] | TA201A-MT01BP | |||
| TOMEI BORE:85.50mm [+0.50] | TA201A-MT01D | |||
| PISTON | for 2.2L/2.3L | CH 31.65mm[-3.35] | TA202A-MT01A | |
CH 31.65mm [-3.35] | TA202A-MT01AP | |||
CH 31.65mm[-3.35] | TA202A-MT01B | |||
| CON-ROD | for 2.0L(STD)/2.2L | 150.00mm [+-0.00] | TA203A-MT01A | |
| for 2.3L | 147.00mm [-3.00] | TA203A-MT01B | ||
| CRANKSHAFT | for 2.2L | Full-C.W. 94.00mm [+6.00] | TA204B-MT01A | |
| for 2.3L | Full-C.W. 100.00mm [+12.00] | TA204B-MT01B | ||
| 4B11 | STROKER KIT | 2.3L | TOMEI BORE: 87.00mm [+1.00] | TA201A-MT02A |
| TOMEI BORE: 86.50mm [+0.50] | TA201A-MT02B | |||
| PISTON | for 2.3L | CH 27.40mm [-6.00] | TA202A-MT02A | |
CH 27.40mm [-6.00] | TA202A-MT02B | |||
| CON-ROD | for 2.0L(STD)/2.3L | 143.75mm [+-0.00] | TA202A-MT02B | |
| CRANKSHAFT | for 2.3L | Full-C.W. 98.00mm [+12.00] | TA204B-MT02A | |
