VQ35DE METAL CATALYZER (Sports Catalytic Converter) |
| @ |
|
CLEAN EMISSIONS & MORE POWER!
ESSENTIAL PARTS IN VQ35DE TUNING. |
| |
Optimized exhaust performance and power output is achieved with this product. After extensive testing with various prototypes and numerous tests. The best design was finally achieved which extracts the best performance that the VQ35DE engine is capable of. |
|
| @ |
| METAL CATALYZER |
Part Number: 193098 |
MSRP $1,670.00 (USD)
|
| ‘ METAL CATALYZER for VQ35DE |
| APPLICATION |
ENGINE |
PART NUMBER |
| Z33 VQ35DE MT/AT |
VQ35DE |
193098 |
|
|
| |
| ‘ DATA |
| MAIN PIPE MATERIAL |
SUS304 |
| MAIN PIPE DIAMETER |
Σ60.5mm |
| MAIN PIPE THICKNESS |
1.5mm |
| BODY DIAMETER |
Σ102mm |
| FIN THICKNESS |
0.1mm |
| NUMBER OF CELLS |
150 |
| FLANGE MATERIAL |
SUS/Fe |
| FLANGE THICKNESS |
11.0/6.0mm |
| WEIGHT |
6.7kg |
|
|
|
| |
|
|
| |
 |
| |
| |
| |
|
| ‘ OPTIMIZED FROM TEST RESULTS |
|
|
|
|
After through testing on the Dyno bench and then additional tests was later conducted on the track in a car running as it would in a race environment. Over a range of tests we had compared other models as well that is available on the market today. This products design is also tested when used in conjunction with other components to find the best product design for balanced performance maximum gains.
|
|
| |
| ‘ EXHAUST PERFORMANCE SUPERIOR @ 150cpsi |
|
|
|
|
It is usual for people to think that the reduction in cell amounts and larger cell holes will give improved performance gains with the reduced exhaust gas restrictions. This is not always the case as our tests have found that the performance gains are not depending on just the number of cells but on all aspects like the thickness and length of the carrier will also have a major influence on the results. So we have chosen the 150cpsi as it is superior with the results achieved. |
|
| ‘ EXPREME HIGH GRADE QUALITY |
|
|
LOST WAX FRONT FLANGE |
 |
|
|
A/F BOSS FOR STOCK SENSORS |
 |
|
|
STOCK O2 SENSOR BOSS |
 |
|
|
PRECISION WELDS |
 |
|
|
|
|
|
| ‘ |
|
| |
| SPEC |
TOMEI |
STD |
| Main Pipe Material |
SUS304 |
Fe |
| Main Pipe Diameter |
Σ60.5mm |
Monaka Process |
| Main Pipe Thickness |
1.5mm |
2.0mm |
| Body Diameter |
Σ102mm |
N/A |
| Fin Thickness |
0.1mm |
N/A |
| Number of Cells |
150 |
N/A |
| Flange Material |
SUS/Fe |
Fe |
| Flange Thickness |
11.0/6.0mm |
11.0/8.0mm |
| Weight |
6.7kg |
12.2kg |
@ |
|
| |
| ‘ SAFETY STANDARDS COMPLIANCE |
|
|
|
Emissions approval certificated is included to show that this complies with Japanese road use regulations.
@ |
|
| |
|
| @ |
| |
| |
VQ35DE METAL CATALYZER RELATED PARTS |
| |
|
EXPREME
EXHAUST MANIFOLDS
Ver.2 |
|
|
|
| @ |
PRODUCT |
APPLICATION |
PART # |
MATERIAL |
PIPE
DIAMETER
(Σ) |
PIPE
THICKNESS
(mm) |
WEIGHT
(k) |
MSRP |
METAL CATALYZER
{
EXHAUST MANIFOLD |
Z33/ CPV35
VQ35DE MT/AT |
415001
|
PIPE |
FLANGE |
HEAT SHEILD |
MAIN: 42.7
TIP: 60.5 |
1.5 |
6.3
(Stock 6.8) |
|
| SUS304 |
STEEL |
SUS304 |
|
|
|
| @ |
|
